Diy quadcopter or build at home then share your experiences. Have any product reveiws, pls contact

Most popular and best motor for fpv racing quadcopter


If you someone looking for an entry or hight level good quality best motor for fpv racing quadcopter such as 180 or 250mm racing mini quad etc? Here some Brushless Motor are recommented for you by pilots. For example 2300 kv with 5045 props and 4s lipo (1300-1800 mah) with high C rating are rated for that kind of crazy power.

Below fpv racing quadcopter using these best Brushless Motor: ZMR250, EMAX250, ZMR 2.4, REVERSE NIGHTHAWK 250, REALFPV SPANKY 5, NIGHTHAWK 250, JPAY QUAD 250, EMAX – NIGHT HAWK 200, LISAM 210, 260 FPV RACER, EMAX NIGHTHAWK 280 #2, STORM TYPE B, NIGHTHAWK PRO 280, STORMRACING SRD260, G-ROTORS 170, FLY CAT 280, HEX 290 FPV, WARPQUAD 230, 3-5S FPV Racing Quqadcopters, etc.

Update PARTS ( It’s worth seeing )

Update 2017-1-22
250 quadcopter motor comparison chart

Motors Size KV Weight Max.Thrust/g(cell:prop@Amp) Price
Cobra 2204 1960 KV 23g 330 (3S : 5030 @ 5.7A) $21
Check
533 (4S : 5030 @ 8.1A)
587 (4S : 5040 @ 11.2A)
Cobra CM2208 2000 KV 44g 579 (3S : 6030 @ 9.6A) $26
Check
912 (4S : 6030 @ 14.4A)
1153 (4S : 6045 @ 22.7A)
FPVModel 2206 2000 KV 33g 586 (3S : 6030 @ 9.0A) $16
570 (4S : 5030 @ 10A)
840 (4S : 6045 @ 21A)
MultiStar 2206 2150 KV 30g 380 (3S : 5030 @ 7.9A) $15
Check
460 (3S : 6030 @ 9.4A)
610 (4S : 5040 @ 13.8A)
LDPower 2206 2200KV 30g 1108 (4S : 5045BN @ 23.4A) $13
Check
1179 (4S : 5040×3 @ 26.4A)
EMAX

Cooling

2204 2300 KV 25g 390 (3S : 5040 @ 8.4A) $18
Check
510 (4S : 5040 @ 10.7A)
620 (4S : 6045 @ 15.7A)
EMax MT 2204 2300 KV 25g 380 (3S : 5030 @ 7.7A) $16
Check
413 (3S : 5040 @ 8.9A)
579 (3S : 6045 @ 14.8A)
DYS BE 1806 2300 KV 18g 415 (3S : 5030 @ 9.0A) $15
Check
485 (3S : 6030 @ 10.2A)
580 (3S : 6045 @ 16.1A)
MultiStar 2204 2300 KV 24g 812 (4S : 5045BN @ 17.2A) $16
Check
814 (4S : 5040×3 @ 18.2A)
Cobra 2204 2300 KV 25g 436 (3S : 5030 @ 8.6A) $21
Check
559 (3S : 6030 @ 11.0A)
SunnySky X2204 2300 KV 21g 442 (3S : 5030 @ 8.5A) $23
Check
539 (3S : 6030 @ 10.0A)
Xnova 2204 2300KV 29g 1090 (4S : 5045BN @ 22.8A) $25
Check
1134 (4S : 5040×3 @ 24.7A)
EMAX RS2205 2300KV 30g 1069 (4S : 5045BN @ 22.7A) $16
Check
1167 (4S : 5045×3 @ 25.4A)
DYS SE2205 2300KV 30g 1066 (4S : 5045BN @ 22.5A) $20
Check
1164 (4S : 5040×3 @ 25.7A)
Cobra

Champion

2205 2300KV 30g 1161 (4S : 5045BN @ 23.8A) $23
Check
1229 (4S : 5040×3 @ 27.4A)
DYS SE2008 2300KV 33g 1255 (4S : 5045BN @ 27.4A) $18
Check
1328 (4S : 5040×3 @ 31.2A)
Edge R2205 2300KV 26.5g 994 (4S : 5045BN @ 20.4A) $18
1031 (4S : 5040×3 @ 23.1A)
Gemfan RT2205 2300KV 31.5g 1150 (4S : 5045BN @ 24.6A) $21
1218 (4S : 5040×3 @ 27.9A)
T-Motor

F40

V2 2300KV 27g 1041 (4S : 5045BN @ 21.1A) $20
Check
1088 (4S : 5040×3 @ 21.8A)
RCINPower GT2205 2300KV 30g 1097 (4S : 5045BN @ 23.6A) $19
1169 (4S : 5040×3 @ 26.1A)
RCTimer FR2205 2300KV 29g 1134 (4S : 5045BN @ 22.8A) $14

Check
1190 (4S : 5040×3 @ 25.0A)
Tornado T1 2205 2300KV 29.5g 1152 (4S : 5045BN @ 23.8A) $25
Check
1223 (4S : 5040×3 @ 27.7A)
Lumenier

RX

2206 2350KV 27g 986 (4S : 5045BN @ 19.1A) $25
Check
1050(4S : 5040×3 @ 21.6A)
Storm M2205 2350KV 25g 1096 (4S : 5045BN @ 23.3A) $23
1127 (4S : 5040×3 @ 25.8A)
Lumenier RX2205 2400KV 24g 1013 (4S : 5045BN @ 21.2A) $26
Check
1037 (4S : 5040×3 @ 24.4A)
RCX SE2205 2400KV 40g 1050 (4S : 5045BN @ 22.6A) $15
1091 (4S : 5040×3 @ 25.1A)
T-Motor

F60

V2 2450KV 33g 1230 (4S : 5045BN @ 25.8A) $26
Check
1400 (4S : 5040×3 @ 32.0A)
Lumenier

SKITZO

RB2204 2500KV 22g 989 (4S : 5045BN @ 23.4A) $29
Check
991 (4S : 5040×3 @ 25.3A)
T-Motor

F40

V2 2500KV 27g 1117 (4S : 5045BN @ 25.1A) $20
Check
1165(4S : 5040×3 @ 27A)
DYS BE1806 2300KV Brushless Motor Black Edition for Multicopters

Rush price under
12.69 (USD)+ Free shipping

DYS BE1806 2300KV Brushless Motor Black Edition for Multicopters

    • Height: 0.85 inches (21.5mm)
    • Width: 0.90 inches (23mm)
    • Weight: 18 grams
    • RPM/V: 2300KV
    • Battery: 2-3S lithium polymer
    • Mounting pattern: 2x 12mm and 2x 16mm
    • Motor mount hole size: M2
    • Output shaft diameter: 2
    • Voltage: 2-3S
    • Max.current: 7.6A
    • Max.power: 84.4W
    • Thrust:

210 Grams (5030 w/ 2S @ 4.4A)
375 Grams (5030 w/ 3S @ 8.0A)
485 Grams (6030 w/ 3S @ 11.0A)


Click Here To Check Current Price

Features:best motor for fpv racing
Low vibration motor great for flying
To make aircraft more stable
Less operating noise
More efficient
Bearings long life

Stuck these on my 180 quad with some 4040 tri blade props and 4s. They simply are the bomb. I got a very light weight setup and these are almost too much for my quad on 4s. Its gonna take some getting used to. They are smooth and well made.best motor for fpv racing

Plugged these into the ZMR250 v2 and got flying pretty fast! Quality seems good, been flying with them for about 2 weeks and haven’t had an issue! Good little motors! I do like the black version specifically for the 250 I build as well!

These motors are mounted on another quad and operation is correct for the kind of flight I do. The box comes with the date of manufacture and with two types of screws M2 5 and 7 mm long enough to hold the motor. Correct delivery as always by Banggood. It would be interesting to have bearings on this engine.

EMAX Cooling New MT2204 II 2300KV Brushless Motor CW CCW for RC Multicopter

Rush price under
15.99 (USD)+ Free shipping

EMAX Cooling New MT2204 II 2300KV Brushless Motor CW CCW for RC Multicopter

  • Framework: 12N14P
  • KV: 2300KV
  • NO. of Cells: 2-3s
  • Max Thrust: 440g
  • Length:29.2MM
  • Shaft: 3MM
  • Propeller: 5inch-6inch
  • Diameter: 27.9MM
  • Weigth:25g

Click Here To Check Current Price

Features:
best motor for fpv racing. Cooling Series, newly designed high-end brushless motor for multirotors
Longer duration of flight, low CG design, lightweight design
Air suction system design, rapid cooling, higher efficiency and longer life
U clip prevents bearing from loosening
High precision CNC machining exquisite design, stern quality control revealing the user’s taste and position
The rotation direction of motor was marked on the front bell, making iteasier to determine rotation direction for CW and CCW motors

Engine for 250 power supply and low demand for current flight time on a packet 2200 30C for about 20 minutes.

Chose between this and the emax 2205 red bottoms and this a good perfect all around ones since the red bottoms are perfect for speed but this one is built for better air or flight time.

Powerful motors but I have had issues with them being “sensitive” when connecting too esc but not with other motors. Fried a couple for seemingly no reason just in setup. No problems with other motors. But when they do work they are great…

One Pair DYS SE2205 2300KV 3-5S Racing Edition Brushless Motor for 180 210 220 FPV Racer

Rush price under
31.99 (USD)+ Free shipping

One Pair DYS SE2205 2300KV 3-5S Racing Edition Brushless Motor for 180 210 220 FPV Racer

  • KV: 2300KV
  • Battery: 3-5S
  • Motor Size:Φ27.7×19
  • Shaft Diameter: 3mm
  • Max.current: 26.8A
  • Max.power: 428.8W

Package Included:
1x  CW Motor
1x  CCW Motor
2x Screw Nut in Black
2x Screw Nut in White
9x Screws (M3*5MM)
9x Screws (M3*7MM)
1x Wrench


Click Here To Check Current Price

Best motor for fpv racing, strong and powerful motor. They are a bit heavy and haea large bearings

RC250 Frame Kit Combo MX2204 Motor 12A ESC 5030 Propeller Mini CC3D FC

Rush price under
89.99 (USD)+ Free shipping

RC250 Frame Kit Combo MX2204 Motor 12A ESC 5030 Propeller Mini CC3D FC

Mini 250 FPV Quadcopter Frame Specifications:
Materials: 3k Weave Carbon Fiber
Fasteners: Stainless Steel + Nylon 6/6
Size: 220mm diagonally, 175mm wide, 130mm long motor-to-motor; about 1/2 the size of a regular quadcopter
Maximum Propeller: 5″
Motor Mount: M2 12mm – 16mm (Tiger MN1806 2300kv, RCX 1804 2400kv), M3 19mm (Tiger MT2206 2000kv, Sunnysky
X2204 2300kv)
Flight Controller Mount: 30.5mm x 30.5mm
Board Camera Mount: 32mm x 32mm
2204 2300KV Motor Specification:
KV Value (RPM/V): 2300
Motor Diameter (mm): 34
Motor Length (mm): 27
Net Weight (g): 33
Weight (g): 43
Color: Black
Shaft Diameter (mm): 3
12A ESC Specifications:
Input Voltage: 2-3S LIPO
Working Current: 12A
BEC: 5V / 1A
Dimensions: 38 x 20 x 6 mm
Weight: 30 g
Package weight: 40G
CC3D Flight Controller Introduction:
Item name:  CC3D Atom/Mini CC3D/CC3D EVO
Size (board only): 30mm x 17mm
Size (in case): 22 x 38 x 12mm WxLxH

Click Here To Check Current Price
Package Included:
1 x Mini 250 FPV Quadcopter Frame (Not assembled)
1 x ESC Connection Board
4 x  Motor (cw 2PCS+ccw 2PCS)
4 x 12A Simonk ESC
2 x 5030 Propeller Pair
1 x MINI CC3D Flight Control Board Se
Features:best motor for fpv racing
With stable performance, it is practical and durable
Offering you high compatibility, reliability and stability
Driving and controlling motor to complete all kinds of instructions
Suitable for 250 Mini four axis and F330 aircraft,etc
It is very popular in retail market
Great Outrunner Brushless Motor
One Pair DYS SE2205 2300KV 3-5S Racing Edition Brushless Motor for 180 210 220 FPV Racer

Rush price under
31.99 (USD)+ Free shipping

One Pair DYS SE2205 2300KV 3-5S Racing Edition Brushless Motor for 180 210 220 FPV Racer

KV: 2300KV
Battery: 3-5S
Motor Size:Φ27.7×19
Shaft Diameter: 3mm
Max.current: 26.8A
Max.power: 428.8W

Package Included:
1x  CW Motor
1x  CCW Motor
2x Screw Nut in Black
2x Screw Nut in White
9x Screws (M3*5MM)
9x Screws (M3*7MM)
1x Wrench


Click Here To Check Current Price

They are packaged in hard case and foam inside. The quality is good. I ordered ccw version hoping for normal thread but this is the left hand threaded shaft. So the version says the thread on the shaft not the direction of rotation.
