Fixed Wing FPV E-flite Convergence Vtol Review

9 min read
3
0
E-flite convergence vtol review

Fixed wing  fpv is become more and more popular, because of it combines multirotor, fpv, plane versatility. Today E-flite convergence vtol review share to you, I definitely recommend this excellent and super fun aircraft. Why? go ahead, after reading this e flite convergence review you will know the reason.

E-flite convergence vtol in box
E-flite convergence vtol in box

Unboxing

What’s in the box? as you see the above image, there are one boboy convergence vtol BNF, two pair propellers, two vertical fins and one user manual in the foam box. Before you flight, need full range at least 6 channels transmitter and 2200-3000mAh 3s lipo battery. If you need FPV system, video transmitter and FPV camera are required. In general, look like very simple to ready to fly. The quality of the E-flite convergence vtol feels pretty good as is expected from Horizon Hobby.



E-flite convergence vtol Assembly

Next step is assemble all the parts, assembling the convergence VTOL is quick and easy as following.

Install the vertical fins

Install the vertical fins on the fuselage using two screws per side as shown.

Install the main propellers

The main propellers are labelled near the hub with an “R” and an “L” to show on which side they should be installed. Install the propeller nut on the collet. Use a small screwdriver or hex wrench through the hole in the propeller nut to tighten. Do not overtighten the propeller nut as damage to the propeller, nut or collet may occur.

E-flite convergence vtol Install propellers
E-flite convergence vtol Install propellers

Install battery

2200mah 3s 30c is recommended by the E-flite official but you can increase the capacity and C-rate for convergence vtol, up to 3000mAah and 50C is also okey. Install the fully charged battery in the battery compartment. Secure using the hook and loop strap. Connect the battery to the flight controller. Refer to the Center of Gravity section to ensure the model balances at the
recommended CG.

E-flite convergence vtol install battery
E-flite convergence vtol install battery

Install FPV system

FPV System InstallationItems required for FPV system installation, there are camera,video transmiter,antenna and video monitor with headset or goggles.

Installation of a video transmitter as shown (right). Connect the lead from the power adapter to the video transmitter harness. Connect the power adapter EC3 plug to the power lead from the flight controller. Thread the video camera connector from the FPV compartment, through the fuselage and to the front of the bottom compartment. Attach the video transmitter antenna to the video transmitter. Replace the video transmitter hatch by gently pushing in on the sides and pressing the hatch straight down into the fuselage.



Flight convergence vtol

The main feature of the convergence vtol is that these two flight modes (stability and acro flight modes) give you a wide range of performance for every phase of flight. You can make transitioning in flight.

Stability modes, in multirotor flight, Stability Mode will limit pitch and bank angles and work to keep the model level when you release the sticks. This allows you to take off and land like a pro, even if you’ve never flown a multirotor before.Stability mode is highly recommended for the fi rst few takeoffs and landings, until you become familiar with how the aircraft reacts to control inputs.

Acro modes,In airplane flight, Acro Mode lets you perform a wide range of aerobatic maneuvers. And because you have the forward thrust of two brushless motors working for you, there is plenty of speed and power to spare.

E-flite convergence vtol ready to fly
E-flite convergence vtol ready to fly

To transition to airplane flight from multirotor flight, change the flight attitude switch on your transmitter to the airplane flight position. The throttle will increase slightly and the motor nacelles will rotate forward in three stages to the airplane flight position.

To transition to multirotor flight from airplane flight, reduce the airspeed, change the flight attitude switch on your transmitter to the multirotor flight position and stability mode for landing.

For your first flights with the recommended battery pack, set your transmitter timer or a stopwatch to 6 minutes.


Video Credit: Discover RC

E-flite convergence vtol Features and Pros

  1. Cutting edge technology,The convergence vtol combines multirotor,fpv,plane versatility.
  2. Assembling the convergence VTOL is quick and easy, even you have never builded a drone or plane before.
  3. Transition to stability mode is smooth and flawless. Transition to acro mode worked great as well.
  4. Can flight both at the flying field and in indoor house, have no mishaps.
  5. Very easy to fly and stable in the wind. Unbelievable power.
  6. Using 2200mAh battery at 3min and have 60% left.

Check Today Deals On Amazon

I definitely recommend this excellent and super fun aircraft E-flite Convergence VTOL

Click The Below Product Links To Purchase

If you purchase the E-flite Convergence VTOL BNF Basic, needed to complate you should need purchase these products, full-range channel transmitter (Highly recommend FrSky Taranis X9D Radio Transmitter ) and 2200-3000mAh 3S LiPo flight battery (Highly recommend E-flite 2200mAh 3S 11.1V 30C battery ).
