Quadcopter frame is important component of quadcopter, There are a lots of quadcopter frame sizes and no thumb rule for size of the frame, but the most common is from 180 mm to 800 mm. Each quadcopter frame with different attributes is designed for different style quadcopter such as fpv / sport racing / cameras / mini etc. Size of wheelbase is quadcopter size. Here talk about quadcopter frame sizes with you.

Frame – The structure that holds all the components together .One of the most important part of quadcopter is its frame because it supports motors and other electronics and prevents them from vibrations. You have to be very precise while making it. They need to be designed to be strong but also lightweight.

quadcopter frame sizes

battery-check-price



Quadcopter frame sizes

If you want to make a quadcopter, but was confused with how to begin and how to choose one. It has been old long talk that you have to clearly know what’s purpose of your quadcopter, fpv / sport racing or cameras etc.?

All parts of quadcopter will be hold on the frame, First , you can decide as to which frame should take? Then, look at the recommended setup of frame to buy other parts. Generally speaking, from 180 mm to 250 mm is most popular frames, more bigger one is from 280 mm to 800 mm even more.

There are some suggestions about quadcopter frame size related to Lipo as below, maybe useful for you , click the original article link to know more Quadcopter suggestions related to Lipo battery

quadcopter suggestions – related to Lipo
quadcopter Type Lipo Batteries
Mini quad lipo 80-800mAh 1s/2s
180 lipo 1000mah/1300mAh 3S/4S
210 lipo 1000mah/1300mAh 3S/4S
250 lipo 1300-1800mAh 3s/4s
280/290 lipo 1500-3300mAh 3s
330/360 lipo 2200-3200mah 4s
400 lipo 3200-3300mah 4S
450 lipo 3300mAh 4S
500 lipo 3300-5000mAh 4s
540 lipo 5000-5200mAh 4s
550/650/750mm lipo 5000-8000mAh 4s/5s/6s
800mm or big lipo 8000mah-30000mah 6s

Quadcopter frame and lipo battery and motor and propeller size matching table

Frame Size Prop Size Motor Size Motor KV Lipo battery
120mm or smaller 3 inch 1104 – 1105 4000KV+ 80-800mAh 1s/2s
150mm – 160mm 3-4 inch 1306 – 1407 3000KV+ 600-900mAh 2s/3s
180mm 4 inch 1806 – 2204 2600KV+ 1000-1300mAh 3s/4s
210mm 5 inch 2204 – 2206 2300KV-2700KV 1000-1300mAh 3s/4s
250mm 6 inch 2204 – 2208 2000KV-2300KV 1300-1800mAh 3s/4s
330mm – 350mm 7, 8 inch 2208 – 2212 1500KV-1600KV 2200-3200mah 3s/4s
450mm – 500mm 9,10,11 inch 2212 – 2216  800KV-1000KV 3300mAh 4s or +



Materials for quadcopter frame

Most available materials for the frame are:

  • Carbon Fiber
  • Aluminium
  • Wood, such as Plywood or MDF (Medium-density fibreboard)
  • Plastic & PVC
  • Fiberglass
 Carbon Fiber  , One of the most common materials for multi-rotor frames is carbon fiber.It is lightweight but expensive. A great many of its physical properties are perfectly suited to the hobby. The only catch is that carbon fiber is known to block radio signals, which is obviously not ideal for a hobby that depends on multiple transmissions. That means you have to exercise a bit of care in how you place antennas on your craft. It can be used though, and is often. Just be aware that blocked signals are a possibility.

 Wood  , Build a frame with wood, It’s fast, low cost and does not require much effort.  while not nearly as sexy as carbon fiber or fiberglass, is a very good material for this sort of thing. It’s cheap, RF transparent, takes brief structural overloads well, uses simple adhesives and dampens vibrations wonderfully.

 Aluminium   is widely used for frame, you need to buy parts and have some tools to cut or connect them together. Very lightweight and aluminum can transmit vibration quite well. Aluminum is easy to fabricate and can often be bent back into shape after crashes.

 Plastic & PVC  , Frame usually be 3D printed with plastic, This material is lightweight, cheap, and perhaps a bit to ugly for your new quadcopter frame as well as PVC.

 Fiberglass  , Another material you could consider is thin G-10 fiberglass sheet which is easily machinable. This is nice for the body area as it’s RF transparent. It also makes nice motor mounts.

Although it is not as important as for the arms which of the three material to use for the center plate, Carbon Fiber and plywood are most commonly seen because of its the light weight, easy to work with and good vibration absorbing features.



Best quadcopter frames

Frame Name Sizes Weight Price
Lisam LS-210 210mm 100g Check Current Price
H250 Carbon Fiber 250mm 145g Check Current Price
YoungRC 450 Quad 450mm 295g Check Current Price

I make sure is that these quadcopter frames are good enough to make it to above list of the best quadcopter frame recommendations.



Best 450 size frames

Frames Materials Sizes Weight Price
RipaFire 450 Quad Glass fiber 450mm 295g Check price
RipaFire F450 4-Axis Carbon Fiber 450mm 282g Check price
Usmile F450 PA66 + 30 GF arm 450mm 322g Check price
Usmile S500 Plastic 450mm 416g Check price

All of them maybe are not the best one, but I make sure thery are highly recommend that you can purchase on of them, which is good enough for your 450mm quadcopter.



Some tips for choosing quadcopter frame

  • Some quadcoper frame can be fine-tuned to suit your exact requirements. such as HobbyKing Switch FPV Quadcopter which By allowing you to choose between 380 and 320 mm wheelbase.
  • In our case we want to build quadcopter so make sure the angle between two arms is 90 degree and also check that arms are not twisted.
  • If your frame is too big compare to your power setup (motor-prop, esc , battery) it will add extra weight while if it’s too small props will fight with each other.
