250mm quadcopter motor recommendations

7 min read
0
0

quadcopter motor recommendationsFor helping you to find the best quadcopter motor, here some 250mm quadcopter motor recommendations for you.

One of the most important parts of a quadcopter is the motor. Being part of the power system, the choice of the motor is critical to the effective functioning of the quadcopter.

Some of the specifications of the motor which may influence your choice include KV, thrust, weight and maximum current.

In choosing the quadcopter motor, you need to know the right size to pick.

This is because if you choose one that is too large then it may end up being heavy for your purpose. On the other and if you choose one that is too small then its performance will be poor and it can easily burn up.

Knowing basic information about the quadcopter motor recommendations such as the revolutions per minute, power and thrust will assist you in making the right choice for your quadcopter motor.

Other choices you may need to make to facilitate the effective driving of the motor include the battery and the ECSs. There are also other options of making your own quadcopter motor.

Want to know more informations, you can read this post How to choose motor for quadcopter .

250mm quadcopter motor recommendations comparison

There are many types of 250 quadcopter motors and hence the need to know the right one to look for.

We will do a comparison of some of these types based on size, revolutions per minute, maximum thrust and price. This information will assist you overcome the confusion of which one to choose.

Motors Size KV W Max.Thrust/g

(cell:prop@Amp)

Price
Cobra 2204 1960KV 23g 330 (3S : 5030 @ 5.7A) $
Check
533 (4S : 5030 @ 8.1A)
587 (4S : 5040 @ 11.2A)
Cobra 2208 2000KV 44g 579 (3S : 6030 @ 9.6A) $
Check
912 (4S : 6030 @ 14.4A)
1153 (4S : 6045 @ 22.7A)
FPVModel 2206 2000KV 33g 586 (3S : 6030 @ 9.0A) $
570 (4S : 5030 @ 10A)
840 (4S : 6045 @ 21A)
MultiStar 2206 2150KV 30g 380 (3S : 5030 @ 7.9A) $
Check
460 (3S : 6030 @ 9.4A)
610 (4S : 5040 @ 13.8A)
LDPower 2206 2200KV 30g 1108 (4S : 5045BN @ 23.4A) $
Check
1179 (4S : 5040×3 @ 26.4A)
EMAX

Cooling

2204 2300KV 25g 390 (3S : 5040 @ 8.4A) $
Check
510 (4S : 5040 @ 10.7A)
620 (4S : 6045 @ 15.7A)
EMax 2204 2300KV 25g 380 (3S : 5030 @ 7.7A) $
Check
413 (3S : 5040 @ 8.9A)
579 (3S : 6045 @ 14.8A)
DYS BE 1806 2300KV 18g 415 (3S : 5030 @ 9.0A) $
Check
485 (3S : 6030 @ 10.2A)
580 (3S : 6045 @ 16.1A)
MultiStar 2204 2300KV 24g 812 (4S : 5045BN @ 17.2A) $
814 (4S : 5040×3 @ 18.2A)
Cobra 2204 2300KV 25g 436 (3S : 5030 @ 8.6A) $
Check
559 (3S : 6030 @ 11.0A)
SunnySky X2204 2300KV 21g 442 (3S : 5030 @ 8.5A) $
Check
539 (3S : 6030 @ 10.0A)
Xnova 2204 2300KV 29g 1090 (4S : 5045BN @ 22.8A) $
Check
1134 (4S : 5040×3 @ 24.7A)
EMAX 2205 2300KV 30g 1069 (4S : 5045BN @ 22.7A) $
Check
1167 (4S : 5045×3 @ 25.4A)
DYS 2205 2300KV 30g 1066 (4S : 5045BN @ 22.5A) $
Check
1164 (4S : 5040×3 @ 25.7A)
Cobra

Champion

2205 2300KV 30g 1161 (4S : 5045BN @ 23.8A) $
Check
1229 (4S : 5040×3 @ 27.4A)
DYS 2008 2300KV 33g 1255 (4S : 5045BN @ 27.4A) $
Check
1328 (4S : 5040×3 @ 31.2A)
Edge 2205 2300KV 26g 994 (4S : 5045BN @ 20.4A) $
1031 (4S : 5040×3 @ 23.1A)
Gemfan 2205 2300KV 31g 1150 (4S : 5045BN @ 24.6A) $
1218 (4S : 5040×3 @ 27.9A)
T-Motor

F40

V2 2300KV 27g 1041 (4S : 5045BN @ 21.1A) $
Check
1088 (4S : 5040×3 @ 21.8A)
RCINPower 2205 2300KV 30g 1097 (4S : 5045BN @ 23.6A) $
1169 (4S : 5040×3 @ 26.1A)
RCTimer 2205 2300KV 29g 1134 (4S : 5045BN @ 22.8A) $
1190 (4S : 5040×3 @ 25.0A)
Tornado T1 2205 2300KV 29g 1152 (4S : 5045BN @ 23.8A) $
Check
1223 (4S : 5040×3 @ 27.7A)
Lumenier

RX

2206 2350KV 27g 986 (4S : 5045BN @ 19.1A) $
Check
1050(4S : 5040×3 @ 21.6A)
Storm 2205 2350KV 25g 1096 (4S : 5045BN @ 23.3A) $
1127 (4S : 5040×3 @ 25.8A)
Lumenier 2205 2400KV 24g 1013 (4S : 5045BN @ 21.2A) $
Check
1037 (4S : 5040×3 @ 24.4A)
RCX 2205 2400KV 40g 1050 (4S : 5045BN @ 22.6A) $
1091 (4S : 5040×3 @ 25.1A)
T-Motor

F60

V2 2450KV 33g 1230 (4S : 5045BN @ 25.8A) $
Check
1400 (4S : 5040×3 @ 32.0A)
Lumenier

SKITZO

2204 2500KV 22g 989 (4S : 5045BN @ 23.4A) $
Check
991 (4S : 5040×3 @ 25.3A)
T-Motor

F40

V2 2500KV 27g 1117 (4S : 5045BN @ 25.1A) $
Check
1165(4S : 5040×3 @ 27A)

Click here to know more informations about 250 quadcopter motor comparison .

Conclusion

In order to buy your 250 quadcopter motor, there is need to compare the revolutions per minute, the thrust and the power capability so as to make the right choice.

By comparing the size and the weight, the flying time and the agility required, then you are most likely to make the right power choice for your quadcopter motor.

With the above 250mm quadcopter motor recommendations comparison, we believe that you will be able to find it much easier when making that critical decision of buying the 250 quadcopter motor.

Important thing to note though is that the 250 quadcopter motor may not be the most expensive one on the market and neither may it be the cheapest. Therefore quality should be the guiding tool in the choice of your motor.
