Quadcopter frame and lipo battery and motor and propeller size matching table

7 min read
3
0

Some motor and propeller questions to alway ask when you diy quadcopter, Today this article show you about quadcopter frame and lipo battery and motor and propeller size matching table, which only for your reference.

Quadcopter components matching table

The main problem with diy your quadcopter is that how to choose the right lipo battery for your frame or how to matching motors and propellers for your quadcopter, The beginner desire to know these problems.

Most of time, you already know quadcopter frame size (Quadcopter frame sizes – which class series quadcopter will you make?) and then choose other components of quadcopter. More generally, it’s a simple way is that frame size limit propeller size and propeller size limit motor size and KV, then limit lipo battery range.

As below table is a matching table for your reference.

Quadcopter frame and lipo battery and motor and propeller size matching table

Frame Size Prop Size Motor Size Motor KV Lipo battery
120mm or smaller 3 inch 1104 – 1105 4000KV+ 80-800mAh 1s/2s
150mm – 160mm 3-4 inch 1306 – 1407 3000KV+ 600-900mAh 2s/3s
180mm 4 inch 1806 – 2204 2600KV+ 1000-1300mAh 3s/4s
210mm 5 inch 2204 – 2206 2300KV-2700KV 1000-1300mAh 3s/4s
250mm 6 inch 2204 – 2208 2000KV-2300KV 1300-1800mAh 3s/4s
330mm – 350mm 7, 8 inch 2208 – 2212 1500KV-1600KV 2200-3200mah 3s/4s
450mm – 500mm 9,10,11 inch 2212 – 2216  800KV-1000KV 3300mAh 4s or +

How to choose the right components for your quadcopter?


The first thing, you may know which frame you plan to getting start for you quadcopter. It’s very importance, because frame size will limit other components size.

motor and propellerIf you do know how many quadcopter frame sizes that there are and where to getting start with? Here are two articles recommended to you, Quadcopter frame sizes – which class series quadcopter will you make? and How to choose the best frame for quadcopter

The second thing, choosing the right motor and propeller for your quadcopter. You can refer to above matching table, the sample is for reference only. You must base on your requirement, Generally,  parameters Required for quadcopter frame will be listed clearly on online shop page or product manual, you just shop them.

For example:

FPV 250MM DIY Frame Kit

Recommanded Part:

Prop:5045 Prop

VTX: 5.8G 40CH Mini Transmitter

Camera: 700TVL Camera

Remote Control Transmitter&Receiver: Flysky i6 Transmitter&iA6 Receiver

Battery: 11.1V 1500mAh Battery

Charger: B3 Balance Charger

ESC: 20A Mini ESC

Motor: 2300KV 2204 Motor

If you need to know more about how to choose quadcopter motor and propeller, Here are some artilces recommended to you.

Before you choosing motors, have to consider quadcopter carry weight then use this formula Required Thrust per motor = ( Weight x 2 ) / 4 to calculate the thrust per motor, And do not forget consider Motor Efficiency, more detail How to choose motor for quadcopter
What’s purpose of building a quadcopter? If you want speed racing then you need to select a very fast turning motor with small propellers. If you want to carry a payload such as a video camera and gimbal then you need to select a slower turning motor with a large propeller . more information How to choose the best propeller for quadcopter
Some motor and propeller questions to alway ask are that RPM calculator / thrust calculator / quadcopter loadweight calculator and propeller calculator, This article was listed and answer these questions and everything else Brushless motor prop calculator.

Conclusion

After diy quadcopter, you will know clearly what you want? how to looking for the right components and put them together on one frame and make sure everything were set up correctly. The important thing is that you can’t believe can fix your quadcopter by yourself when it crah, which is often the case.

The point is to choose the right motor and propeller and match each other in the process of diy quadcopter. Above match table is only for reference, and may be varied at data. If you have any questions or share your experiences on here, please leave your messages.
